Features:
1): High performance PC diffuser, higher lumen;
2): IP65 rated Waterproof structure design;
3): Aluminum based LED module for better heat dissipation;
4): Easy connect the power supply;
5): Square bulkhead;
Specification：
|
Type
|
Product |
IP65 BULKHEAD |
||
|
|
Model No. |
HI-C05XXP SERIES |
||
|
Specification |
HI-C05220W |
HI-C05280W |
HI-C05330W |
|
|
Dimension |
220*220*55MM |
280*280*55MM |
330*330*55MM |
|
|
Input Voltage |
AC 220-240V |
AC 220-240V |
AC 220-240V |
|
|
Power |
12W |
18W |
24 W |
|
|
Flickering |
Non-flickering |
Non-flickering |
Non-flickering |
|
|
Flux |
1080 lm |
1620lm |
2160lm |
|
|
Color Temperature |
2700K-6500K |
|||
|
CRI (Ra>): |
Ra>80 |
Ra>80 |
Ra>80 |
|
|
Material |
PC Diffuser+ Plastic base（ABS/PC for choice) |
|||
|
IP Rating |
IP65 |
|||
|
Certificate |
CE/RoSH |
|||
|
Working Temp. |
-20℃-40℃/-4°F-104°F |
|||
HI-C05XXP SERIES
IP65 Bulkhead
