Features:
1):200mm width, precision model integrated molding iron;
2): Nice outlook with even light output;
3): Ceiling or suspended mounted;
4): Widely application, quite nice used for commercial lighting;
5): Both white and black color for choice, white type's lumen will be better since black type will absorb the lumen;
Specification:
|
Type |
Product |
LED BATTEN LIGHT |
||
|
Model No. |
HI-L01XXGSERIES |
|||
|
Specification |
HI-L0120G |
HI-L0140G |
||
|
General |
Dimension(L×W×H) |
L600*W200*H60mm |
L1200*W200*H60mm |
|
|
Power |
24W |
45W |
||
|
Luminous Flux |
1800lm |
3375lm |
||
|
DF |
>0.7 |
>0.9 |
||
|
PF |
>0.5 |
>0.9 |
||
|
Net weight |
1225g |
1950g |
||
|
Flicker |
Non Flicker/Ripple free |
|||
|
Input Voltage |
AC185~265V |
|||
|
Ambient Temperature |
-25~45 ℃ |
|||
|
Material |
Iron(Painted white/black color)PC |
|||
|
Electrical Grade |
||||
|
Protection Grade |
IP20 |
|||
|
Installation |
Ceiling& Suspending |
|||
|
Optical |
CCT(K) |
|||
|
CRI |
||||
|
Quality |
Guarantee |
3 Years |
||
|
Certification |
Satisfying EMC conduction / EMC radiation / EMC surge standard |
|||
